Intramedullary Fixation of Diaphyseal Clavicle Fractures Using the Rockwood Clavicle Pin: Review of 86 Cases

INTRODUCTION

Fractures of the clavicle are common, accounting for 2.6% to 4% of adult fractures and 35% of injuries to the shoulder girdle [1-3]. Fractures of the shaft account for between 69% and 82% of all clavicle fractures [1, 3]. Undisplaced fractures of the clavicle shaft often heal with good clinical outcomes following non-operative management and there is general consensus that these should be treated non-operatively [4]. Outcomes following non-operative management of displaced mid-clavicular fractures are far less favourable than was once perceived, with several studies observing increased rates of non-union and symptomatic malunion [5-8]. A meta-analysis of articles addressing the treatment of displaced mid-clavicular fractures between 1975 and 2005 revealed a 15.1% non-union rate for closed treatment, 2.2% with compression plating, and 2% with intramedullary fixation [8]. Residual disability as measured by deficits in shoulder strength and endurance, as well as reduced patient satisfaction have also been observed in non-operatively treated displaced clavicle shaft fractures [9]. A recent multicenter randomised prospective clinical trial has shown improved functional outcome, lower rates of non-union and malunion following operative treatment of displaced clavicle fractures [10]. Factors associated with non-union and the development of long term sequelae following non-operative management of mid-clavicular fractures include displacement (in particular shortening of > 2 cm), comminution and advancing age [8]. Internal fixation of clavicle fractures is most commonly performed with plating. Intramedullary fixation has been previously described using Knowles pins [11, 12], Kirschner wires [13], Hagie pins [14] and elastic intramedullary nails [15-17]. While fixation with a plate involves a significant scar over the fracture area to allow placement of screws along the plate’s length, intramedullary fixation may be achieved with a much smaller scar at the fracture site and a second scar posterolaterally. The key evolutionary step between the Rockwood pin and previous intramedullary devices is that the threaded medial end and lateral locking nut allow both compression at the fracture site and resistance to migration of the metalwork. The purpose of this paper is to share the results of our experience with the Rockwood clavicle pin (DePuy, Warsaw, Indiana) in the treatment of acute diaphyseal clavicle fractures and non-union as an alternative to plate fixation.

MATERIALS AND METHODOLOGY

All cases of middle third clavicle fracture or non-union seen at one centre between February 2004 and February 2011 were included in the study. Of the 1086 cases, 985 patients were treated conservatively, 86 (7.9%) were treated by intramedullary fixation using the Rockwood clavicle pin and 15 (1.4%) underwent fixation with a plate. Indications for fixation were gross displacement of the fracture causing tenting of the skin, an open fracture or shortening by more than 20mm. Plate fixation was used in cases where the fracture extended proximally along the clavicle preventing the threaded medial end of the pin from gaining purchase, or distally preventing the locking nut from compressing the construct.

Of the 86 patients treated by Rockwood pin fixation, 70 (81.4%) underwent Rockwood pin fixation acutely or sub-acutely within 16 weeks of the injury (group A). Cases treated subsequent to the 16 week point were considered as surgery for symptomatic non- or mal-union since union would be expected by this time (group B). The mean time to surgery was 18 (2-64) days in group A and 28.3 (4.0-240.7) weeks in group B. Delays to surgery in group A were the result of late presentation e.g. injury abroad, failed initial non-operative management due to subsequent fracture displacement, or polytrauma requiring initial treatment of more serious injuries.

Higher numbers of males underwent fixation in both groups – 53 vs 17 in group A and 13 vs 3 in group B. The mean age was similar for each group – 34.4 in the group A and 38.1 in group B. The dominant side was injured in around half of cases in each group. Fractures were classified according to the Edinburgh system [3]. Two raters (WJM & PR) independently scored the radiographs and in the case of discrepancy, the senior author (MW) rated the radiograph for a third time. The most common subtype was 2B1 (Fig. 1A). In the group of patients treated by Rockwood pin fixation, the proportion of each sub-classification of fracture was similar to that seen in the group treated by plate fixation. 18 segmental 2B2 fractures were observed of which 17 were treated by Rockwood pin (Table 1).

The mechanism of injury was varied with the highest proportion of patients in the acute group sustaining injuries from road traffic collision (RTC), particularly involving a motorcycle or bicycle. A similar range of mechanisms caused the injuries in the group B (Table 2).

All procedures were performed by three Consultant orthopaedic surgeons specialising in upper limb trauma, with the majority of cases (79, 92%) performed by the senior author.

Case notes and radiographs were retrospectively reviewed to facilitate fracture classification and assess the incidence of complications. Measurements of pre and post-operative clavicle lengths were conducted using the Picture Archiving and Communication System (PACS) to assess for correction of shortening using the following method. Post-operative radiographs were standardised using the known diameter of the pin used in that patient. True post-operative length of the clavicle was then calculated. A bony landmark was then measured on both the pre-and post-operative films and the pre-operative film was standardised to the post-operative one. The true pre-operative length was calculated. If there was rotational difference between films, length could not be calculated. Functional outcome and patient satisfaction were measured by means of the Disability of the Arm, Shoulder and Hand (DASH) outcome measure [18] and an overall procedure related satisfaction questionnaire. Significance of correction of shortening and difference in length of stay was analysed using Student’s T-test. Statistics were calculated using Excel (Microsoft, WA USA).

Surgical Technique

The Rockwood clavicle pin was inserted as described in the manufacturer’s technique manual [19]. Patients were placed in the beach chair position and following sterile draping, a 3cm skin incision was made over the fracture site parallel to Langer’s lines. The fracture was exposed by dividing the fibres of the platysma taking care to avoid injury to the middle branch of the supraclavicular nerve which usually lies just below it. Towel clips were used to grasp the medial and lateral fragments which were then sequentially drilled and tapped. The Rockwood pin was inserted antegrade into the lateral fragment using a Jacobs chuck and T-handle. The pin was then passed through the posterior cortex of the lateral fragment and exited through the skin via a small stab incision where it was retrieved laterally. Once the pin had retracted sufficiently into the lateral fragment, the fracture was reduced and the pin was passed retrogradely into the intramedullary canal of the medial fragment. Finally, two locking nuts were fitted to compress the fracture if needed, and to secure the pin laterally (Fig. 2). The Rockwood pins used in each group were of a similar size of median 3.8mm. Allomatrix Injectable Putty (Wright Medical Technology, Arlington, TN) was used in 20% of acute fractures in the presence of significant comminution and in 87.5% of cases in group B. The pin was then trimmed below the skin, and both incisions were sutured. All patients received prophylactic intravenous antibiotics at induction. Postoperatively patients were placed in a sling for 2 weeks. They were then instructed to resume activities of daily living as tolerated but avoid strenuous activities such as pulling, lifting or pushing and arm elevation higher than face level for 4 to 6 weeks. Patients were routinely listed for removal of Rockwood pin when there was clinical and radiological evidence of union 16 weeks post-operatively. Radiographic union was defined as the appearance of bridging callous. If there was evidence of delayed union, removal of the pin was postponed.

RESULTS

In group A, the pins were removed at a mean of 3.6 months and follow-up was for a mean of 7.1 months. Functional assessments and satisfaction measures were carried out at a mean of 45 months. In group B, the pins were removed at a mean of 5.5 months and follow-up was for a mean of 8.7 months. Functional assessments and satisfaction measures were carried out at a mean of 34 months.

Sixty-eight fractures in group A went on to unite (Fig. 1A-C). The two cases of non-union were revised using a contoured locking plate and bone graft. There were no cases of non union in the group B although one case had not united at 8 months when the pin was removed – this was treated expectantly and united after a further 18 months (Table 3).

The predominant complication in both groups was posterior pin prominence causing significant irritation which resulted in wound oozing with or without superficial infection in several of the cases. Consequently four wounds in the acute group broke down exposing metalwork. Two of these underwent trimming at 14 and 48 days following pin insertion. The remaining two cases were managed expectantly with regular wound dressing until fracture union and pin removal. In all cases, symptoms of irritation resolved following hardware removal (Table 3).

One intra-operative complication was encountered which involved fracture of a drill tip while drilling the medial fragment. The broken tip was left in situ and due to its small size, no difficulties were encountered introducing or removing the pin following fracture union (Table 3).

The pre-operative shortening was corrected in the post-operative films by 8mm in group A and 6mm in group B. This was statistically significant in group A and showed a strong trend in group B (Table 4).

A reasonable response to DASH and satisfaction questionnaires was obtained – 71% in group A and 81% in group B. The mean DASH score was similar for both groups: 5.9 for group A and 8.7 for group B. All responders said they would have the procedure again and, although the vast majority of the acute group rated their satisfaction as good or excellent, 7.7% of group B rated their outcome as fair (Table 5).

DISCUSSION

LIMITATIONS

Shortcomings of our study include the relatively small number of procedures performed and the short follow-up period. The retrospective nature of data collection, incompleteness of the functional outcome scores obtained and the lack of a control for comparison are also acknowledged. Despite this, our series is the largest of its kind and gives a robust picture of patient centred and clinical outcomes when using Rockwood clavicle pins.

CONCLUSION

Complications can be reduced by using purpose-designed Rockwood pin cutter, the use of bone graft in comminuted fractures and non-union, ensuring the lateral pin exit point is inferior and that the correction in shortening does not leave a void. There does appear to be a higher rate of irritation symptoms in patients with a slim build.

Rockwood pins appear to be as effective as plates in achieving union and maintaining length in both the acute and delayed setting with the advantages of smaller skin incisions and less periosteal disruption than a plate. Although they seemingly avoid the potentially catastrophic risks of migration seen in other intramedullary devices, the rate of pin prominence and need for a further procedure present a significant disadvantage. The 100% union rate in the delayed fixation group is promising, however the numbers in this group were small and an extended study is required to validate this. In choosing between plate and Rockwood pin fixation, one should weigh this less invasive technique against its potential for inconvenience and complications.
