CASE REPORT


A Complicated Course of a Coronal Shear Fracture Type IV of the Distal Part of Humerus Resulting in Resurfacing Radiocapitellar Joint Replacement



Ingo Schmidt*
SRH Poliklinik Gera Gmbh, Straße des Friedens 122, Gera 07548, Germany


Article Metrics

CrossRef Citations:
3
Total Statistics:

Full-Text HTML Views: 1034
Abstract HTML Views: 428
PDF Downloads: 335
ePub Downloads: 262
Total Views/Downloads: 2059
Unique Statistics:

Full-Text HTML Views: 614
Abstract HTML Views: 297
PDF Downloads: 223
ePub Downloads: 213
Total Views/Downloads: 1347



Creative Commons License
© 2017 Ingo Schmidt.

open-access license: This is an open access article distributed under the terms of the Creative Commons Attribution 4.0 International Public License (CC-BY 4.0), a copy of which is available at: https://creativecommons.org/licenses/by/4.0/legalcode. This license permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.

* Address correspondence to this author the SRH Poliklinik Gera GmbH, Straße des Friedens 122, Gera 07548, Germany, Tel: 122-07548; Email: schmidtingo62@googlemail.com


Abstract

Background:

Coronal shear fracture type IV of the distal part of humerus is a very rare injury with articular complexity potentially leading to posttraumatic osteoarthritis. One option for surgical treatment of advanced unicompartmental radiocapitellar osteoarthritis is resurfacing radiocapitellar joint replacement.

Method:

A 62-year- old female sustained a coronal shear fracture type IV of the distal part of left humerus that was primarily treated with open reduction and internal fixation using headless compression screws. Three years postoperatively, there was a migration of one screw into radiocapitellar joint that led to circular deep cartilage defect of radial head. Four years after ORIF, a distinctive radiocapitellar osteoarthritis has evolved leading to a resurfacing radiocapitellar joint replacement using the Lateral Resurfacing ElbowTM (LRE) system.

Result:

At the 2-year follow-up after that procedure, there was an excellent subjective and functional outcome. Radiographically, no loosening or subsidence of implant without any signs of overstuffing could be found. The patient reported that she would have the same procedure again.

Conclusion:

The goal of unicompartmental radiocapitellar replacement is to obtain stability in elbow joint by avoiding cubitus valgus with subsequent instability of the distal radioulnar joint, and it does not alter the unaffected ulnohumeral joint. Additionally, the feature of the LRETM system is that the radial head is not excised, and so will receive the anatomical length of the overall radius articulating with the capitellum by preserving the annular ligament. In the literature only three publications could be found in which short-term results with the use of the LRETM system have been described. Hence, further studies are needed to validate this concept.

Keywords: Coronal shear fracture, Elbow, Headless compression screw, Posttraumatic osteoarthritis, Radiocapitellar joint, Unicompartmental resurfacing joint arthroplasty.



INTRODUCTION

Coronal shear fractures (CSFs) of the distal part of humerus involving the capitellum and/or trochlea are rare injuries with articular complexity, and account for less than 1% of elbow fractures [1, 2]. Bryan and Morrey [3] classified capitellar fractures into four types, and McKee et al. [4] later modified type IV. Type I (i.e. Hahn-Steinthal fracture) is complete capitellar fracture with little or no extension into the lateral trochlea typically associated with anterior displacement, type II (i.e. Kocher-Lorenz fracture) is minimal osteochondral fracture typically associated with posterior displacement, type III (i.e. Broberg-Morrey / Grantham fracture) is comminuted/compression capitellar fracture, and type IV (McKee's modification of type I) is a shear fracture of the distal part of humerus that extends in the coronal plane across the capitellum to include most of the lateral trochlea ridge and the lateral half of the trochlea, identified by the presence of the pathognomonic “double arc sign” on lateral radiograph.

Complex fracture of the distal part of humerus represents a challenging therapeutic problem. It can lead to mild to moderate posttraumatic and/or postoperative osteoarthritis (OA) in up to 74% of cases at an average of 19 years, and in 40% of all cases subsequent procedures are necessary, however, clinical symptoms does not often correlate with the extend of radiographic signs [5]. The Lateral Resurfacing ElbowTM (LRETM, Biomet, Warsaw , Indiana/USA) arthroplasty is one system that is currently in use [6-8]. We present one complicated course of the very rare CSF type IV resulting in posttraumatic unicompartmental radiocapitellar OA that was treated with this system, and a technical note of implant and short review of literature will highlight this relatively new procedure.

TECHNICAL NOTE LRETM SYSTEM

The uncemented LRETM system is composed of two monoblock components (Fig. 1a) and it was created and first described in 2007 by Pooley [6]. The system is available in 4 sizes (small / medium / large / extra-large). The spherical capitellar component is manufactured from cobalt-chrome (CoCr) alloy; and it has an extended skirted rim and tapered, cruciform, hydroxyapatite (HA)-coated peg to ensure secure press-fit fixation. The peg is to be inserted in direction of anatomic capitellar axis which is usually angled 50-60° anterior to the axis of the humeral shaft (Fig. 1b). When isolated capitellar OA is present, it can be used as unicompartmental capitellar hemiarthroplasty, and there is an option for use in a cemented manner if the bone stock is poor. The radial head component has a tapered, HA-coated, cruciform CoCr stem connected to a metal-backed ultra-high molecular weight (UHMW) polyethylene (PE) articulation that provides a cortical frame around the UHMW PE offset. The peg is to be inserted in the direction of anatomic radial neck axis which is usually angled 15° lateral to the axis of the radial shaft (Fig. 1b).

Fig. (1). (Technical Note LRETM system): (a) Photograph demonstrating the metal-on-UHMW PE articulation. (b) PA an lateral fluoroscopy intraoperatively showing correct insertion of radial and capitellar components in direction of their axes, and intraoperative clinical photograph showing the cortical frame around the offset of radial UHMW PE component (arrows).

CASE PRESENTATION

A 62-year-old female presented with a CSF type IV of the distal part of left humerus after a fall on her left outstreched arm, in which his left hand took the force of the impact on the ground. On examination, there was swelling and distinctive pain-related decrease of motion in her left elbow. The diagnosis was confirmed radiographically and with the use of three-dimensional (3D) computed tomography (CT) scans. The lateral radiograph showed anterior displacement of the trochlea as well as the capitellum of 30° to normal that was associated with the “double arc sign” (Fig. 2a). The open reduction and internal fixation (ORIF) through a dorsal incision was detected and the elbow joint was exposed through an oblique osteotomy of the lateral column of distal part of humerus. The trochlea as well the capitellum were anatomically reducted using seven 2,4 mm headless compression screws in antegrade as well as retrograde manner, and the osteotomy of the lateral column of distal part of humerus was anatomically reducted using three 3,5 mm cortical compression screws (Fig. 2b). After surgery, the left arm was immobilized in a plaster splint for two weeks. Then, the elbow's motion was freed, and strenghtening was started after the sixth postoperative week.

Fig. (2). (Case Presentation): (a) Lateral radiograph and 3D CT scan demonstrating CSF type IV with anterior displacement of trochlea as well as capitellum of 30° (lines, points), note the pathognomonic "double arc sign" (arrows). (b) PA radiograph after primary ORIF showing correct alignment of the distal part of humerus without step-off in both articular surfaces.

The further course was uncomplicated. Three years later, the patient reported increasing pain during supination and pronation of the left forearm that was clinically associated with crepitus in the radiocapitellar joint, and an elbow's extension deficit with 15° compared to the unaffected right elbow. The lateral radiograph showed intraarticular migration of one headless compression screw despite complete union of CSF (Fig. 3a). All three screws primarily inserted into capitellum were removed (Fig. 3b), and the patient was pain free for another year.

Fig. (3). (Case Presentation): (a) Lateral radiograph three years after ORIF showing migration of one of the headless compression screws into radiocapitellar joint (arrow) despite complete union of CSF. (b) Lateral radiograph after removal of all three headless compression screws of capitellum showing no signs of posttraumatic/postoperative OA.

One year after partial removal of headless compression screws, the patient reported increasing pain in her left elbow joint again. The posteroanterior (PA) radiograph showed distinctive posttraumatic OA of the capitellum without any signs of degenerative changes of radial head (Fig. 4a). According to these findings, the capitellar hemiarthroplasty with capitellar component of the LRETM system was primarily detected through a dorsal incision. In contrast to the radiograph, intraoperatively there was additionally a deep circular cartilage defect of radial head due to the formerly backing out of a headless compression screw (Fig. 4a). Hence, the uncemented radiocapitellar replacement using both components of the LRETM system was performed (Fig. 1b). Postoperative radiographs showed correct alignment of implant without any signs of overstuffing (Fig. 4b). After surgery, the left arm was immobilized in a plaster splint for two weeks. Then, the elbow's motion was freed, and strengthening was started after the sixth postoperative week.

Fig. (4). (Case Presentation): (a) PA radiograph and intraoperative clinical photograph four years after ORIF including one year after partial removal of headless compression screws showing distinctive OA of the capitellum (yellow arrows) without any signs of degenerative changes of radial head radiographically, but intraoperatively there was pronounced deep circular cartilage defect (white arrows). (b) PA and lateral radiographs showing correct positioning and alignment of LRE™ system without any signs of overstuffing.

At the 2-year follow-up after unicompartmental radiocapitellar replacement; radiographically, there was no change in the position of LRETM implant, and with no signs of loosening, subsidence, or overstuffing. Elbow flexion was with 150° equal to contralateral, and the lateral radiograph with terminal range of motion revealed no impingement between both prosthetic components (Fig. 5a). Elbow extension showed unchanged a deficit of 15° compared to the unaffected right elbow, and the lateral radiograph with terminal range of motion revealed no impingement between both prosthetic components as well (Fig. 5b) Supination with 90° and pronation with 90° showed no functional deficits compared to the unaffected right forearm (Fig. 5c). The elbow performance improved from 64 (fair) before LRETM arthroplasty to 92 (excellent) in the Mayo Elbow Performance score (MEPS, 0 - 100 points). The patient reported that she would have the same procedure again.

Fig. 5. (Case Presentation): (a) Clinical photograph and lateral radiograph demonstrating elbow flexion of 150° of both arms, and there is no impingement between both prosthetic components with terminal range of motion. (b) Clinical photograph and lateral radiograph of elbow extension demonstrating a deficit of 15° to contralateral, and there is no impingement between both prosthetic components with terminal range of motion. (c) Clinical photographs showing each 90° supination and pronation of both forearms.

DISCUSSION

Although not a weight-bearing joint, the elbow is subjected to considerable forces whose resultant can reach three times the weight of the body at the ulnohumeral and radiocapitellar joints during heavy labour [9]. The mechanism of injury in CSFs is fall on outstreched arm, and often direct axial compression of radial head with capitellum is responsible for fracture pattern [10]. When axial loading is associated with varus stress, the trochlea can be fractured alone, and it is often associated with elbow dislocation [4, 11].

CSFs are usually associated in up to 40% of cases with lateral collateral ligament injuries, and in up to 30% of cases with radial head fractures [1, 12, 13]. The incidence is higher among women because of their high rate of osteoporosis and carrying angle difference than men [14, 15]. In addition to trauma with or without resulting malunion, unicompartmental radiocapitellar OA may occur by rheumatoid arthritis, osteochondritis dissecans, crystal-induced arthropathies such as gout, sequelae of septic arthritis, and avascular osteonecrosis (Morbus Panner). For the development of degenerative or posttraumatic changes in the elbow, Goodfellow and Bullough [16] first described in 1967 that the articular cartilage with ageing in radiocapitellar joint is much more vulnerable than in ulnohumeral joint, and it can be caused by the specific geometry of elbow joint which is anatomically determined for load transmission.

ORIF of CSF provides anatomical reduction, stability and early mobilization, and has become the preferred surgical treatment. Closed reduction, immobilization or fragment excision are generally associated with poor outcomes [12, 15]. For ORIF, the use of headless compression screws has proven to be a suitable and reliable option [10, 13, 17]. However, intraarticular migration of a headless compression screw despite complete union of fracture after anatomical reduction, such as in our case, can be a concern. It has also been observed in the wrist in 14% of patients who underwent carpal fusions [18], and can lead in single case to a total wrist arthroplasty [19].

Generally, treatment options of unicompartmental radiocapitellar OA are excisional procedures or joint replacement. However, capitellar excision creates instability in coronal plane when medial structures are disrupted and poor clinical outcomes were reported in more than 50% of patients [1, 20]. Radial head resection increases the mechanical stresses on the ulnar compartment, worsens the valgus, and carries a risk of proximal radial migration with ulnar variance alteration at the wrist. Isolated radial head resection is therefore controversial [21].

Resurfacing unicompartmental radiocapitellar replacement offers a new and fascinating option for the treatment of osteoarthritis and rheumatoid arthritis when the lateral compartment is prevalently involved [22, 23]. The aim of unicompartmental radiocapitellar replacement is to obtain stability in elbow joint by avoiding cubitus valgus with subsequent instability of the distal radioulnar joint, and it does not alter the unaffected ulnohumeral joint. The goal of the LRETM system is that the radial head is not excised, and so will receive the anatomical length of the overall radius articulating with the capitellum; and additionally, the annular ligament remains preserved. However, in the literature only three publications could be found in which short-term results of resurfing radiocapitellar replacement or capitellar hemiarthroplasty using the LRETM system with a total of 36 evaluated patients (averaged 53.3 years old) have been described [6-8]. Twenty-nine patients (80.6%) rated their outcome in MEPS according to Morrey and Adams [24] with excellent or good, four patients (11.1%) with fair, and three patients (8.3%) with poor. None of all implants showed loosening radiographically. Complications in detail were one case with deep infection, one case with a triceps muscle dehiscense, one case with neuropathy of ulnar nerve, three cases with joint stiffness, two cases with heterotopic ossifications, and one case with primary faulty positioning of capitellar component. The elbow's extension deficit of 15° that was observed in our case is mostly based on posttraumatic OA before resurfacing unicompartmental radiocapitellar replacement with the LRETM system.

When applying the LRETM arthroplasty, the main implant- and/or iatrogenic insertion- related concern is probably overstuffing that was found in 25% of cases by Giannicola et al. [7]. This specific complication is also known with the use of radial head replacement and Copeland resurfing humeral head implant [25, 26]. Overstuffing of elbow joint is defined as radiographic widening of the lateral ulnohumeral joint space due to insertion of an radial head and/or radiocapitellar implant that is too thick, and it can clinically lead to loss of flexion, stiffness, pain and capitellar wear. The diagnosis is often difficult to confirm; for that cases, comparing radiographs of the uninjured elbow is likely the best investigation to consider [27]. Removal of implant combined with radial head resection can be considered as salvage option after a failed unicompartmental radiocapitellar replacement using the LRETM system.

LIST OF ABBREVIATIONS

3D  = Three-dimensional
CoCr  = Cobalt-chrome
CSF(s)  = Coronal shear fracture(s)
CT  = Computed tomography
HA  = Hydroxyapatite
LRE  = Lateral Resurfacing Elbow
MEPS  = Mayo Elbow Performance score
OA  = Osteoarthritis
ORIF  = Open reduction and internal fixation
PA  = Posteroanterior
PE  = Polyethylene
UHMW  = Ultra high molecular weight

CONFLICT OF INTEREST

The author confirms that this article content has no conflict of interest.

ACKNOWLEDGEMENTS

Decleared none.

REFERENCES

[1] Lee JJ, Lawton JN. Coronal shear fractures of the distal humerus. J Hand Surg Am 2012; 37(11): 2412-7.
[2] Yari SS, Bowers NL, Craig MA, Reichel LM. Management of distal humeral coronal 18 shear fractures. World J Clin Cases 2015; 3(5): 405-17.
[3] Bryan RS, Morrey BF. Fractures of the distal humerus. In: Morrey BF, Ed. The elbow and its disorders. Philadelphia, USA: WB Saunders 1985; pp. 325-33.
[4] McKee MD, Jupiter JB, Bamberger HB. Coronal shear fractures of the distal end of the humerus. J Bone Joint Surg Am 1996; 78(1): 49-54.
[5] Doornberg JN, van Duijn PJ, Linzel D, et al. Surgical treatment of intra-articular fractures of the distal part of the humerus. Functional outcome after twelve to thirty years. J Bone Joint Surg Am 2007; 89(7): 1524-32.
[6] Pooley J. Unicompartmental elbow replacement: Development of a Lateral Replacement Elbow (LRE) arthroplasty. Tech Shoulder Elbow Surg 2007; 8(4): 204-12.
[7] Giannicola G, Angeloni R, Mantovani A, et al. Open debridement and radiocapitellar replacement in primary and post-traumatic arthritis of the elbow: a multicenter study. J Shoulder Elbow Surg 2012; 21(4): 456-63.
[8] Heijink A, Morrey BF, Eygendaal D. Radiocapitellar prosthetic arthroplasty: A report of 6 cases and review of the literature. J Shoulder Elbow Surg 2014; 23(6): 843-9.
[9] Chadwick EK, Nicol AC. Elbow and wrist joint contact forces during occupational pick and place activities. J Biomech 2000; 33(5): 591-600.
[10] Singh AP, Singh AP. Coronal shear fractures of distal humerus: Diagnostic and treatment protocols. World J Orthop 2015; 6(11): 867-76.
[11] Mehdian H, McKee MD. Fractures of capitellum and trochlea. Orthop Clin North Am 2000; 31(1): 115-27.
[12] Dubberley JH, Faber KJ, Macdermid JC, Patterson SD, King GJ. Outcome after open reduction and internal fixation of capitellar and trochlear fractures. J Bone Joint Surg Am 2006; 88(1): 46-54.
[13] Mighell M, Virani NA, Shannon R, Echols EL Jr, Badman BL, Keating CJ. Large coronal shear fractures of the capitellum and trochlea treated with headless compression screws. J Shoulder Elbow Surg 2010; 19(1): 38-45.
[14] Guitton TG, Doornberg JN, Raaymakers EL, Ring D, Kloen P. Fractures of the capitellum and trochlea. J Bone Joint Surg Am 2009; 91(2): 390-7.
[15] Ring D, Jupiter JB, Gulotta L. Articular fractures of the distal part of the humerus. J Bone Joint Surg Am 2003; 85-A(2): 232-8.
[16] Goodfellow JW, Bullough PG. The pattern of ageing of the articular cartilage of the elbow joint. J Bone Joint Surg Br 1967; 49(1): 175-81.
[17] Dressler HB, de Paula RN. Bryan and Morrey type IV intra-articular fracture of the distal extremity of the humerus treated surgically with anterior access: case report. Rev Bras Ortop 2015; 50(3): 352-5.
[18] Richards AA, Afifi AM, Moneim MS. Four-corner fusion and scaphoid excision using headless compression screws for SLAC and SNAC wrist deformities. Tech Hand Up Extrem Surg 2011; 15(2): 99-103.
[19] Schmidt I. An unusual and complicated course of a giant cell tumor of the capitate bone. Case Rep Orthop 2016 Article ID 3705808.
[20] Watts AC, Morris A, Robinson CM. Fractures of the distal humeral articular surface. J Bone Joint Surg Br 2007; 89(4): 510-5.
[21] Chammas M. Post-traumatic osteoarthritis of the elbow. Orthop Traumatol Surg Res 2014; 100(1 Suppl): S15-24.
[22] Giannicola G, Sacchetti FM, Antonietti G, Piccioli A, Postacchini R, Cinotti G. Radial head, radiocapitellar and total elbow arthroplasties: a review of recent literature. Injury 2014; 45(2): 428-36.
[23] Bigazzi P, Biondi M, Ceruso M. Radiocapitellar prosthetic arthroplasty in traumatic and post-traumatic complex lesions of the elbow. Eur J Orthop Surg Traumatol 2016; 26(8): 851-8.
[24] Morrey BF, Adams RA. Semiconstrained arthroplasty for the treatment of rheumatoid arthritis of the elbow. J Bone Joint Surg Am 1992; 74(4): 479-90.
[25] Birkedal JP, Deal DN, Ruch DS. Loss of flexion after radial head replacement. J Shoulder Elbow Surg 2004; 13(2): 208-13.
[26] Mechlenburg I, Amstrup A, Klebe T, Jacobsen SS, Teichert G, Stilling M. The Copeland resurfacing humeral head implant does not restore humeral head anatomy. A retrospective study. Arch Orthop Trauma Surg 2013; 133(5): 615-9.
[27] Rowland AS, Athwal GS, MacDermid JC, King GJ. Lateral ulnohumeral joint space widening is not diagnostic of radial head arthroplasty overstuffing. J Hand Surg Am 2007; 32(5): 637-41.
