RESEARCH ARTICLE


Arthroplasty in the Valgus Knee: Comparison and Discussion of Lateral vs Medial Parapatellar Approaches and Implant Selection



Jai Rawal, Adam J Devany*, James A Jeffery
Department of Orthopaedics and Trauma, Queen Elizabeth Hospital, King’s Lynn, PE30 4ET, UK


Article Metrics

CrossRef Citations:
13
Total Statistics:

Full-Text HTML Views: 1433
Abstract HTML Views: 332
PDF Downloads: 653
Total Views/Downloads: 2418
Unique Statistics:

Full-Text HTML Views: 785
Abstract HTML Views: 234
PDF Downloads: 418
Total Views/Downloads: 1437



Creative Commons License
© Rawal et al.; Licensee Bentham Open.

open-access license: This is an open access article licensed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/3.0/) which permits unrestricted, non-commercial use, distribution and reproduction in any medium, provided the work is properly cited.

* Address correspondence to this author at the Department of Orthopaedics and Trauma, Queen Elizabeth Hospital, King’s Lynn, PE30 4ET, UK; E-mail: adamdevany@doctors.net.uk


Abstract

Constrained implants are frequently used for primary total knee arthroplasty (TKA) in patients with moderate and severe genu-valgum (>10˚). This deformity presents corrective challenges for ligament release. The lateral-parapatellar approach has been advocated as an alternative to the traditional medial-parapatellar approach. Claimed advantages include better access for release of tight ligamentous structures, without requirement for release of the medial-collateral ligament.

We present our comparative experience of the use of an unconstrained knee-replacement prosthesis inserted by the lateral-parapatellar approach in comparison to a constrained-knee prosthesis inserted via the medial-parapatellar approach.

49 primary total knee-replacements in 48 (6 males, 42 females) patients were performed; 32 through a lateral-parapatellar approach (group L) using an unconstrained-prosthesis and 17 through a medial-parapatellar approach more often requiring a constrained-prosthesis (group M). Mean preoperative valgus angle was 18.5 (range 11-34˚). Patient demographics (p=0.7) and valgus correctability were similar between the two groups.

There was no significant difference in the mean post-operative valgus angle. This was 4.2˚ (range 1-9.5˚) using the lateral-parapatellar approach and 5.3˚ (range 0.3-10˚), p=0.12, using the medial-parapatellar approach.

Transient common peroneal injury occurred in 2 patients, both group L, in the presence of valgus angles of greater than 20˚. To date no joints have been revised, or are unstable.

The use of a lateral-parapatellar approach, appropriate soft tissue release, and an unconstrained PCL-preserving implant, yielded in all cases a stable, well aligned knee arthroplasty. This represents a viable alternative to the constrained-prosthesis using a medial-parapatellar approach in patients with moderate and severe genu-valgum.

Keywords: Lateral parapatellar approach, mechanical tibio-femoral axis, unconstrained, valgus knee, varus-valgus constrained. .



INTRODUCTION

The valgus knee can present greater challenges of ligament balance in total knee arthroplasty in comparison to varus aligned knees [1]. Restoration of neutral mechanical axis and correct ligament balance are important factors to reduce incidence of complications relating to instability, loosening, premature wear and patella mal-tracking [2-5].

The option of using a constrained or an unconstrained (PCL retaining) implant for arthroplasty of the moderate to severely valgus knee remains an area of controversy [6]. Some surgeons consider the valgus knee to be a relative contraindication to implanting an unconstrained prosthesis [7].

Optimised survival rates have been reported with restoration of overall alignment between 2.4° and 7.2° valgus, with failure of varus aligned knees through medial bone collapse and valgus aligned knees with ligamentous instability [8]. Multiple papers support the importance of correct alignment in increasing implant longevity [9-12], through the reduction of strain at the implant bone interface [13].

Variability exists in the reported survivorship of unconstrained implants performed on valgus deformed knees, with some authors reporting Kapplin Meier survival at 10 years of 79% from all causes (80% with instability as an endpoint) [14], yet others suggesting a 96.2% 10 year survival in knees with 20° or more valgus [6].

There remains debate regarding the use of unconstrained prosthesis in the valgus knee. The lateral parapatellar approach has been advocated as an alternative to the medial parapatellar approach in the valgus knee as release of tight lateral structures is facilitated with the approach.

METHODS

Retrospective comparison was conducted on two groups of patients with surgery undertaken by two experienced knee surgeons (J.J. & N.C.), using two separate approaches and implant constraints. We sought to establish whether the use of a lateral parapatellar approach with an unconstrained implant provided similar angle of correction and stability as a medial parapatellar approach using mostly constrained prosthesis.

Patients with a preoperative valgus deformity >10o were identified from hospital medical records and radiographs. Tibio-femoral alignment (TFA) was assessed using a digital goniometer (IMPAX) and analysed by a single author (JR). Postoperative radiographs were analyzed in a similar way. Specific long leg films were not available.

Medical records and radiographs were reviewed for demographic details and for post-operative complications and revision surgery. Data handling and analysis was conducted using Microsoft Excel spreadsheet and SPSS.

Patients underwent a total knee arthroplasty through either a lateral parapatellar approach, as described by Fiddian [15], using an unconstrained implant in all cases (group L, surgeon J.J.) or through a medial parapatellar approach, as described by Ranawat [5], using a variety of constrained and unconstrained implants (group M, surgeon N.C.).

RESULTS

Forty-nine total knee replacements were performed in 48 patients (42 women and 6 men) with a tibiofemoral angle of greater than 10° who underwent primary total knee arthroplasty between September 2004 and October 2011. Thirty-two arthroplasties were performed through a lateral parapatellar approach of which all had an unconstrained AGC knee implanted (group L). 17 total knee arthroplasties were performed through a medial parapatellar approach using a variety of constrained and unconstrained implants as shown in Table 1 (group M).

Table 1.

Summary of results.


  Group L Group M P Value
Patient number 32
M:F = 1:9.7
17
M:F = 1:4.7

0.7
Age (years) 73.7 70.1 0.3
BMI 31.7 29.9 0.6
Pre-op correctability
(clinically judged)
0.76˚ 0.83˚ 0.07
Level of prosthesis constraint 32 unconstrained 6 unconstrained
5 posterior stabilised
5 high post/varus-valgus constrained
1 fully constrained

Mean pre-op TFA 18.5˚ ( range 13-29˚) 18.4˚ ( range 10.1-34˚)
Mean post-op TFA 4.1˚ (range 1-9.5˚) 5.6˚ (range 0.3-10˚) 0.05
Complications Transient common peroneal nerve palsy: 2 patients Superficial wound infection: 3 patients

There were no significant differences between group L and M regarding age, BMI or preoperative TFA.

Group L had a statistically significant lower TFA postoperatively in comparison to group M (4.1˚ vs 5.6˚, respectively, p=0.05). Furthermore there were 4 knees with a postoperative TFA greater than 8° in group M, and only 1 in group L.

There were no reported cases of patella maltracking, instability or revision from any cause in either group. There were also no proven deep infections in either group, however, group M had 3 superficial wound infections; group L did not have any. There were two cases of common peroneal nerve injury, both were found in group L.

DISCUSSION

Approximately 15% of patients have significant valgus deformity (>10 degrees) [16]. There remains debate as to what the most effective and reliable method of achieving patient satisfaction, deformity correction and long-term prosthesis survival.

Different options exist for surgical approach and prosthesis selection. The traditional medial parapatellar approach in the valgus knee requires access to the lateral structures to achieve balance [5]. In the experience of one of the authors (J.J.) this can present difficulty of clear access and identification of these structures.

As shown in Fig. (1), medialising the mechanical axis in the corrected valgus knee overcomes the medial collateral ligament laxity, resulting in a stable and functional joint achieved using an unconstrained prosthesis. Fig. (2) shows this concept with a highly valgus knee of 20o being overcorrected to 3o of valgus.

Fig. (1).

Diagram illustrating slight overcorrection of valgus deformity with an unconstrained implant to achieve a stable and well balanced knee.


Fig. (2).

Pre and post-operative radiographs of unconstrained implant in corrected valgus knee.


The alternative use of the lateral parapatellar approach, as described by Fiddian, allows for easier access to tight lateral structures which can be sequentially released [15]. Additionally no further release of the already stretched medial collateral ligament is required in this approach.

We recognise limitations exist within our study, including: limited formal post-operative follow-up beyond 1 year, although it is assumes that patients with significant problems would re-attend.

Apostolopoulos et al. [16] also described the value of a lateral parapatellar approach for patients with severe valgus deformity (15-35o, mean = 23o), reporting good outcomes in correction of deformity (2-7o, mean = 5.5o) and osteotomy union in all 24 patients. Their approach also incorporated tibial tubercle osteotomy to improve access and for mechanical realignment purposes, which we found not to be necessary in our patient group. They described the value of the lateral parapatellar approach in the valgus knee as giving improved access to release tight lateral structures and the potential to incorporate lateral release as part of the surgical approach.

Our study highlights that the lateral parapatellar approach is a safe option in correcting the moderate to severe valgus knee, with appropriate soft tissue release, and an unconstrained PCL-preserving implant as a viable alternative to the use of the medial parapatellar approach and greater levels of implant constraint.

In all cases the lateral approach yielded a stable, well aligned knee arthroplasty.

CONFLICT OF INTEREST

The authors confirm that this article content has no conflict of interest.

ACKNOWLEDGEMENTS

The authors acknowledge the permission of Mr N, Coleman for inclusion of his patients in this study.

REFERENCES

[1] Girard J, Amzallag M, Pasquier G , et al. Total knee arthroplasty in valgus knees predictive preoperative parameters influencing a constrained design selection Orthop Traumatol 2009; 95(4): 260-6.
[2] Ranawat CS, Rose HA, Rich DS. Total condylar knee arthroplasty for valgus and combined valgus-flexion deformity of the knee Instruct Course Lect 1984; 33: 412.
[3] Whiteside LA. Correction of ligament and bone defects in total arthroplasty of the severely valgus knee Clin Orthop Relat Res 1993; 288: 234-45.
[4] Whiteside LA. Selective ligament release in total knee arthroplasty of the knee in valgus Clin Orthop Relat Res 1999; 367: 130-40.
[5] Ranawat AS, Ranawat CS, Elkus M. Total knee arthroplasty for severe valgus deformity J Bone Joint Surg Essent Surg Technol 2005; 87(1_suppl_2 ): 271-84.
[6] Kubiak P, Archibeck MJ, White RE Jr. Cruciate-retaining total knee arthroplasty in patients with at least fifteen degrees of coronal plane deformity J Arthroplasty 2008; 23(3): 366-70.
[7] Elkus M, Ranawat CS, Rasquinha VJ. Total Knee Arthroplasty for Severe Valgus Deformity.Five to fourteen-year follow-up J Bone Joint Surg 2004; 86(12): 2671-6.
[8] Fang DM, Ritter MA, Davis KE. Coronal alignment in total knee arthroplasty just how important is itκ J Arthroplasty 2009; 24(6): 39-43.
[9] Tew M, Waugh W. Tibiofemoral alignment and the results of knee replacement J Bone Joint Surg Br 1985; 67(4): 551-6.
[10] Karachalios TH, Sarangi PP, Newman JH. Severe varus and valgus deformities treated by total knee arthroplasty J Bone Joint Surg Br 1994; 76(6): 938-42.
[11] Ritter MA, Faris PM, Keating EM, Meding JB. Postoperative alignment of total knee replacement its effect on survival Clin Orthop Relat Res 1994; 299: 153-6.
[12] Lonner JH, Siliski JM, Scott RD. Prodromes of failure in total knee arthroplasty J Arthroplasty 1999; 14(4): 488-92.
[13] Perillo-Marcone A, Taylor M. Effect of varus/valgus malalignment on bone strains in the proximal tibia after TKR an explicit finite element study J Biomech Eng 2007; 129(1): 1-11.
[14] Koskinen E, Remes V, Paavolainen P , et al. Results of total knee replacement with a cruciate-retaining model for severe valgus deformity-A study of 48 patients followed for an average of 9 years Knee 2011; 18(3): 145-50.
[15] Fiddian NJ, Blakeway C, Kumar A. Replacement arthroplasty of the valgus knee A modified lateral capsular approach with repositioning of vastus lateralis J Bone Joint Surg Br 1998; 80(5): 859-61.
[16] Apostolopoulos AP, Nikolopoulos DD, Polyzois I , et al. Total knee arthroplasty in severe valgus deformity Interest of combining a lateral approach with a tibial tubercle osteotomy Orthop Traumatol Surg Res 2010; 96(7): 777-84.
